Meprolight MVO 1-8x28mm FFP M1,MRAD – Matte Black Anodized Green/Red Reticle – 901245701

MVO™ 1-8X28 is a highly sought-after choice for the AR15 platform and other comparable carbines designed for dynamic, fast-paced engagements at close to medium ranges. This scope features a versatile variable magnification, beginning at 1x for rapid target acquisition and moving up to higher magnifications for more precise shots at greater distances. Its adaptability makes it ideal for a variety of shooting scenarios, whether you’re on the move or in a stationary position. Known for its all-around capability, the LPVO is often regarded as the perfect general-purpose optic for those who require flexibility and performance across multiple ranges.

Featuring the M1 MIL Reticle, it is an MRAD Speed Ring reticle made for CQB to mid-range shooting. The M1 MIL Reticle provides a separated cross-hair for easy aiming. An illuminated CQB circle at lower magnifications allows users to quickly place shots by placing close range targets within the circle. At 1x magnification, the circle can be used similarly to a red dot sight for fast target acquisition. At distance, convenient shoulder-to-shoulder references quickly estimate range without cluttering the view of the target. Miliradian (MRAD) holdover stadia line aid users in distance compensation.

Tech Spec
Overall Length    10.9” (276.9 mm)
Weight (w/ battery)    25.3 oz (717.1 g)
Tube Diameter    34mm
Eyepiece length    3.39” (86.1 mm)
Rear Mounting Space    2.64” (67.1 mm)
Front Mounting Space    2.17” (55.1 mm)
Objective Length    1.06” (26.9 mm)
Outer Objective Bell Diameter    1.38” (35.1 mm)
Outer Eyepiece Diameter    1.81”
Threaded Objective Bell    Yes
Battery Cap    Twist Cap
Housing Material    6061-T6 Aluminum
Actual Magnification    1.0x – 8.0x
Focal Plane    First Focal Plane
Objective Lens Diameter    28 mm
Eye Relief (inches)    3.7” (94.0 mm)
Linear Field of View (ft @ 100 Yds)    1x: 115.5 8x: 14.1
Parallax Control    Fixed @ 100 yds
Diopter Type    Adjustable, Friction Secured
Reticle    M1 MRAD
Reticle Type    Etched Glass
Reticle Illumination    Yes
Reticle color(s)    Red and Green, Daylight Bright
Range Estimation    Yes (Yards)
Caliber Rating    .338 Lapua Magnum
Exposed optical surface treatment    Broadband anti-reflection coating of all glass-to-air interfaces
Glass components    Extra Low Dispersion (ED) & High Definition (HD) Schott Glass
Turret Style    Tactical, Locking.
Elevation: Exposed, adjustable
Windage: Exposed, adjustable
Zero Reset    Yes
Zero Stop    No
Turret unit of measurement    MRAD
Throw Tab with Lever Extension    Yes
Windage and Elevation – 1 click increment    0.1 MRAD
Total Elevation Adjustment UP    19 MRAD
Total Elevation Adjustment DOWN    13.5 MRAD
Elevation Adjustment per Revolution    10 MRAD (Total 32 MRAD)
Total Windage Adjustment    15 MRAD, 7.5 MRAD per side
Windage Adjustment per Revolution    10 MRAD
Battery Type    CR2032 3V
Battery Loading    Left Turret
Distinct sight brightness levels not including OFF    10 Red, 10 Green
NV brightness levels    2
Brightness Mode(s)    Manual
Battery life, minimum time of use at brightness setting 5 of 10 with approved battery at Ta1    600 hours (@ mid setting)
Power ON/OFF    Rotary Turret
Auto Power-Off Duration    12-hr auto-off
Water resistance, minimum depth exposure without leak into optical or battery cavity    IPX-8
Operating Low temperature    -40°F (-40°C) (Conform to MIL-STD-810G)
Operating High temperature    +160°F (70°C) Conform to MIL-STD-810G)
Storage temperature    -40°F (-40°C)
Housing Finish Coating/Color    Type II Anodize, Matte Black
Sun Shade    No
Throw Lever Extension    Yes
Flip-Style Lens Caps    Yes
